Working Conditions: pressure: = 400 bar. Speed: = 0,5 m/s. Temperature: -40°c + 110°c
|
MÃ HÀNG |
d |
d |
h |
|
TTI 1513 |
14.00 |
22.00 |
6.30 |
|
TTI 1527 |
18.00 |
24.00 |
5.20 |
|
TTI 1536 |
20.00 |
28.00 |
6.30 |
|
TTI 1545 |
22.00 |
32.00 |
8.00 |
|
TTI 1550/1 |
25.00 |
33.00 |
6.30 |
|
TTI1573 |
30.00 |
40.00 |
8.00 |
|
TTI 1593/1 |
35.00 |
45.00 |
8.00 |
|
TTI 1634/2 |
45.00 |
55.00 |
7.00 |
|
TTI 1650 |
50.00 |
60.00 |
8.00 |
|
TTI 1650/1 |
50.00 |
60.00 |
8.00 |
|
TTI 1652 |
50.00 |
60.00 |
11.00 |
|
TTI 1664 |
50.00 |
68.00 |
10.00 |
|
TTI 1703 |
60.00 |
75.00 |
11.00 |
|
TTI 1734 |
65.00 |
80.00 |
11.00 |
|
TTI 1752 |
70.00 |
85.00 |
12.50 |
|
TTI 1806 |
90.00 |
105.00 |
9.50 |
|
TTI 1831 |
100.00 |
115.00 |
11.50 |
|
TTI 1846 |
110.00 |
125.00 |
12.00 |
|
TTI 1876 |
125.00 |
145.00 |
13.00 |
|
TTI 1900 |
140.00 |
160.00 |
16.00 |
Working Conditions: pressure: = 250/500 bar. Speed: = 0,5 m/s. Temperature: -30°c + 120°c
|
MÃ HÀNG |
d |
d |
h |
m |
|
TSE 2030 |
28.00 |
38.00 |
8.00 |
36.50 |
|
TSE 2034 |
30.00 |
40.00 |
7.50 |
38.50 |
|
TSE 2036 |
32.00 |
40.00 |
9.00 |
38.50 |
|
TSE 2038 |
35.00 |
43.00 |
6.50 |
41.50 |
|
TSE 2038/1 |
35.00 |
43.00 |
8.00 |
41.50 |
|
TSE2055 |
40.00 |
50.00 |
10.00 |
48.50 |
|
TSE 2065 |
45.00 |
55.00 |
8.00 |
53.50 |
|
TSE 2066 |
45.00 |
55.00 |
11.00 |
53.50 |
|
TSE 2073 |
50.00 |
60.00 |
8.00 |
58.50 |
|
TSE 2074 |
50.00 |
60.00 |
10.00 |
58.50 |
|
TSE 2104 |
65.00 |
80.00 |
11.50 |
78.50 |
|
TSE 2108 |
70.00 |
80.00 |
8.00 |
78.50 |
|
TSE 2130 |
80.00 |
96.00 |
10.50 |
94.50 |
|
TSE2136 |
90.00 |
100.00 |
10.50 |
98.50 |
|
TSE 2148 |
90.00 |
110.00 |
12.50 |
108.50 |
|
TSE 2153 |
100.00 |
115.00 |
11.50 |
113.50 |
Working Conditions: pressure: = 250/500 bar. Speed: = 0,5 m/s. Temperature: -30°c + 120°c
|
MÃ HÀNG |
d |
d |
h |
m |
|
TSE 2030 |
28.00 |
38.00 |
8.00 |
36.50 |
|
TSE 2034 |
30.00 |
40.00 |
7.50 |
38.50 |
|
TSE 2036 |
32.00 |
40.00 |
9.00 |
38.50 |
|
TSE 2038 |
35.00 |
43.00 |
6.50 |
41.50 |
|
TSE 2038/1 |
35.00 |
43.00 |
8.00 |
41.50 |
|
TSE 2055 |
40.00 |
50.00 |
10.00 |
48.50 |
|
TSE 2065 |
45.00 |
55.00 |
8.00 |
53.50 |
|
TSE 2066 |
45.00 |
55.00 |
11.00 |
53.50 |
|
TSE 2073 |
50.00 |
60.00 |
8.00 |
58.50 |
|
TSE2074 |
50.00 |
60.00 |
10.00 |
58.50 |
|
TSE 2104 |
65.00 |
80.00 |
11.50 |
78.50 |
|
TSE 2108 |
70.00 |
80.00 |
8.00 |
78.50 |
|
TSE 2130 |
80.00 |
96.00 |
10.50 |
94.50 |
|
TSE 2136 |
90.00 |
100.00 |
10.50 |
98.50 |
|
TSE 2148 |
90.00 |
110.00 |
12.50 |
108.50 |
|
TSE 2153 |
100.00 |
115.00 |
11.50 |
113.50 |
